    It's been a while since I last built PC (2012 Q6600 build) so it is time to bring things up to date with a Kaby Lake build.

    First few parts arrived - Phanteks P400 case, Intel G4560 CPU and this piece of artwork arrived today - Gigabyte Z170X Gaming 7. I've never owned a so called premium motherboard so this is a nice addition to the build and also gives me headroom for CPU upgrade possibilities.

    [​IMG]Motherboard by Stuart Pardue, on Flickr

    You are probably wonder why I am opting for a Sky Lake board with a Kaby Lake CPU. The reason is there isn't much change between a Z170 and Z270 boards bar extra PCI lanes so it seemed more apt to buy Sky Lake board and flash the Bios for Kaby Lake CPU's.

    My last build was all about speed in an enclosed case. This time round its all about aesthetics and showing off the internal workings through the window of the Phanteks case so there will be cable management galore going on with custom braided cabling to tie in the theme.

    More updates soon!

    NickTB, amfoto, Suomi and 3 others like this.
  2. asaspasas6

    asaspasas6

    Messages:
    1,508
    Name:
    Andrius
    Edit My Images:
    No
  3. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Did a little test fit tonight of the motherboard in the case.
    Snug as a bug as they say and considering this is a budget case its got plenty of space inside and the cable management routes line up nicely with the key connectors on the board.

    Dead space at front will house either a 240/280 or 360mm AIO cooler for the CPU. Quite look the look of the NZXT Krakens :D

    [​IMG]Motherboard mock up by Stuart Pardue, on Flickr

    david357, amfoto, minnnt and 3 others like this.
  4. Chuckoir

    Chuckoir

    Messages:
    885
    Name:
    Steve
    Edit My Images:
    Yes
    You've probably already got this covered, but worth bearing in mind that you might need to update the BIOS to get it to work with the Kaby Lake CPU.

    Look forward to seeing the build completed.

  5. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Yeah its already on the latest bios beforeci purchased it so im covered.
    Worst case scenario would have been to buy a cheap sky lake pentium to update it.

  6. neil_g

    neil_g

    Messages:
    30,246
    Name:
    Neil
    Edit My Images:
    No
    seen random CPU throttling issues on kaby/skylake hardware mixes. something to look out for.

    HP have got into quite a lot of bother over it for example.

  7. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Will watch out for that (y)
    The plus point i guess is i could easily go out an buy a 2nd hand i3 6100 if the G4560 doesnt play ball

  8. Phil White

    Phil White

    Messages:
    264
    Edit My Images:
    Yes
    I have just built a Kaby Lake system. I used the following key components... I7 7700k... EVGA GTX1080 Classified... 32gb DDR4 3200mhz... MSi Z270 X-Power Gaming Titanium board. Using the Corsair H115i CPU cooler.

  9. Chuckoir

    Chuckoir

    Messages:
    885
    Name:
    Steve
    Edit My Images:
    Yes
    Have you attempted to overclock your 7700k yet?

  10. Brazo

    Brazo

    Messages:
    1,662
    Name:
    Mark
    Edit My Images:
    Yes
    I'm running a 7700k. I haven't really overclocked it. I have set all four cores to x45 and temps are ok but at this stage I wouldn't want to go any higher. I demand absolute silence and am using a bequiet dark rock pro 3 on silent settings which works great at being quiet but doesn't cool enough (in silent mode) to make me want to increase the multiplier.

    I am toying with the idea of a delid but will wait for coffeelake now as if it works on z270 boards I will upgrade to a 6 core coffeelake cpu as it will be easier to sell the 7700k intact.

  11. Phil White

    Phil White

    Messages:
    264
    Edit My Images:
    Yes
    Yes I am running it at 4.8ghz without any issues. My motherboard has a simple to use over clock function, simply turn a dial on the board and press a button and the over clock is done. I believe it can go up to 5.1ghz if needed.

    Of course I have adequate cooling from the Corsair H115i CPU cooler.

  12. Chuckoir

    Chuckoir

    Messages:
    885
    Name:
    Steve
    Edit My Images:
    Yes
    Nice. No issues I assume? Have read a fair bit around issues with the 7700k temp spiking when putting any sort of voltage through it, which is odd to say the least.

    Anyway, apologies OP, I've derailed your thread! Keep us updated with your progress! :)

  13. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Not need to apologise. All relevant to the context of the thread (y)

  14. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Thread title changed as my G4560 has mysteriously disappeared and has been replaced with an i3 6100.
    This wasnt my intention but i got the i3 for a smidge more than i sold the G4560.
    Plus if i want to have a punt at overclocking it then a BCLK is simple enough on these boards and should be good for 4.4/4.5Ghz.

    All fun and games!

    Chuckoir likes this.
  15. Mikesphotaes

    Mikesphotaes

    Messages:
    7,402
    Name:
    Mike
    Edit My Images:
    Yes
    Just built a new Win10 PC using that very CPU.

    Very quiet with the stock cooler too!

    stupar likes this.
  16. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Ive heard its good. Wouldnt pay full wack for it but the 2nd hand price was a steal.
    I will be hooking mine up to either a Corsair Hydro or NZXT Kraken 240mm Radiator to keep things cool.

  17. Chuckoir

    Chuckoir

    Messages:
    885
    Name:
    Steve
    Edit My Images:
    Yes
    Good luck!

    stupar likes this.
  18. Chuckoir

    Chuckoir

    Messages:
    885
    Name:
    Steve
    Edit My Images:
    Yes
    What GPU are you dropping in it, by the way? Or are you using the onboard graphics?

  19. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    As the only game that will be played on it will be the wifes Sims 4 it doesnt need a potent GPU.
    I was planning on dropping in a GTX 580 or 660.
    To be honest i have my heart set on an Asus GTX 580 Direct CUII. Its a decent card even though old, it has a cover on the back which fits in with the keeping the inside of the case looking neat and tidy.
    The only downside is its a power hungry card and has two 8 pin sockets to power it. Not that thats an issue as PSU is going to be an EVGA 650W GQ so will give plenty room for such a GPU.

  20. asaspasas6

    asaspasas6

    Messages:
    1,508
    Name:
    Andrius
    Edit My Images:
    No
    unless you have gtx580/gtx660 already you can use them for sure... otherwise just get nice cheap gtx1050 (less electricity bills to pay) which will be fine for sims 4 :D

  21. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Just a micro update as my time and money is being sucked up elsewhere.

    Got my 3 Corsair 120mm fans installed in exhaust mode. Next up will be deciding on what 240mm AIO cooler to get.

    [​IMG]Fans fans fans by Stuart Pardue, on Flickr

  22. Chuckoir

    Chuckoir

    Messages:
    885
    Name:
    Steve
    Edit My Images:
    Yes
    I've got a Thermaltake AIO in mine and I've got no complaints - keeps my 6700k nice and cool, although the NZXT Kraken you mentioned earlier does look good. I'm a sucker for flashy lights so if I was to buy one again, it'd probably be one of those.

  23. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Another wee update.
    Decided on a colour change from red to white so changed the Corsair fan rings and bought some Shakmods white braided mobo, CPU & front panel cables.
    One I know what GPU is going in I will then do the same white braided 6/8 pin pcie cables.
    [​IMG]P1040020 by Stuart Pardue, on Flickr

    amfoto, Chuckoir and minnnt like this.
  24. Chuckoir

    Chuckoir

    Messages:
    885
    Name:
    Steve
    Edit My Images:
    Yes
    Looking good! Where did you order your braided cables from? Was it Amazon? I keep meaning to pick some red/black ones up for mine.

  25. stupar

    stupar

    Messages:
    6,623
    Name:
    Stuart
    Edit My Images:
    Yes
    Shakmods sell them through Amazon and i had a 30 quid amazon voucher so it made sense.
    Their not cheap cables but they do look good if you are into custom builds and epic cable management.

  26. NickTB

    NickTB

    Messages:
    1,620
    Name:
    Nick
    Edit My Images:
    Yes
    Subscribed with interest.
